US $700 - 1,000 / Set
Product Name: Paperless Recorders DXAdvanced DX2048-3-4-2/A4/C2/P1/USB1 |
| Port: | wuhan,guangzhou |
|---|---|
| Supply Ability: | 3000 Set/Sets per Month |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union |
| Packaging Details: | with best carton or according to customer's requirement |
|---|
Specifications
DXAdvanced (DX1000/DX2000) represents the next-generation Daqstation with new enhancements to most functions.
Yokogawa Paperless Recorders DXAdvanced® DX2000
OVERVIEW:
The DX1000 is a DAQSTATION that displays real-time measured data on a color LCD and saves data on a CompactFlash memory card (CF card). It can be hooked up to network via Ethernet, which enables to inform by Email and to monitor on Web site as well as to transfer files by using FTP. Also, it can communicate with Modbus/RTU or Modbus/TCP.
It comes with a two, four, six-channel or twelve-channel model. As the input signal, a DC voltage, thermocouple, resistance temperature detector, or contact signal can be set to each channel. The data saved on a CF card can be converted by data conversion software to Lotus 1-2-3, Excel, or ASCII format file, facilitating processing on a PC. Not only this, the Viewer software allows a PC to display waveforms on its screen and to print out waveforms.
Basic Functions:
- Up to 48 channels of input
- Start/stop recording by batch, and create data files
- Expandable to up to 348 channels with the MW100 automatic connection function
- Internal memory increased to 400 MB
- Enables control of calibration correction scheduling
- Automatically creates template-based Excel spreadsheets
Display & Operation:
- Arrange the display your way with a custom display function!
- Review historical data with date and time calendar search function
Networking
- Standard Ethernet interface
- Supports the PROFIBUS-DP and EtherNet/IP protocols!
- Expanded Web and networking functions!
Reliability and Security
- 21 CFR Part 11 compliance with an advanced security function option
- Dust- and splash-proof front panel (IP65, NEMA4 compliant)
- Highly reliable internal memory with error-correction function
- Front panel door lock and login function
Model | Suffix code | Optional code | Description |
| code | |||
| DX2004 | 4 ch, 125 ms(Fast sampling mode: 25 ms) | ||
| DX2008 | 8 ch, 125 ms(Fast sampling mode: 25 ms) | ||
| DX2010 | 10 ch, 1 s(Fast sampling mode: 125 ms) | ||
| DX2020 | 20 ch, 1 s(Fast sampling mode: 125 ms) | ||
| DX2030 | 30 ch, 1 s(Fast sampling mode: 125 ms) | ||
| DX2040 | 40 ch, 1 s(Fast sampling mode: 125 ms) | ||
| DX2048 | 48 ch, 1 s(Fast sampling mode: 125 ms) | ||
| Internal memory | -3 | 400 MB | |
| External media -4 | CF card (with media) | ||
| Display language -2 | English, degF, DST(summer/winter time) | ||
| Options | /A1 | Alarm output 2 points *1 | |
| /A2 | Alarm output 4 points *1 *12 | ||
| /A3 | Alarm output 6 points *1 | ||
| /A4 | Alarm output 12 points *1 *9 *12 | ||
| /A5 | Alarm output 24 points *1 *2 *8 *12 | ||
| /C2 | RS-232 interface *3 | ||
| /C3 | RS-422/485 interface *3 | ||
| /D5 | VGA output | ||
| /F1 | FAIL/Status output *2 *4 *9 | ||
| /F2 | FAIL + Alarm output 22 points *1 *4 *8 *12 | ||
| /H2 | Clamped input terminal (detachable) | ||
| /H5 | Desktop type (for /P1 model, without power code, screw type power terminal) *5 | ||
| /H5[ ] | Desktop type *6 | ||
| /M1 | Mathematical functions *12 | ||
| /N1 | Cu10, Cu25 RTD input/3 leg isolated RTD | ||
| /N2 | 3 leg isolated RTD *7 | ||
| /N3 | Extended input type (PR40-20, Pt50, etc.) | ||
| /P1 | 24 VDC/AC power supply *5 | ||
| /R1 | Remote control *12 | ||
| /TPS4 | 24 VDC transmitter power supply (4 loops) *8 | ||
| /TPS8 | 24 VDC transmitter power supply (8 loops) *8 *9 *12 | ||
| /KB1 | Easy text entry (with input terminal) *10 *11 | ||
| /KB2 | Easy text entry (without input terminal) *10 | ||
| /USB1 | USB interface | ||
| /PM1 | Pulse input (including remote control and mathematical functions) *12 | ||
| /CC1 | Calibration correction function | ||
| /MC1 | External input function *13 | ||
| /BT2 | Multi-batch functions *14 | ||
| /CP1 | PROFIBUS-DP functions *3 | ||
| /AS1 | Advanced security functions (Part 11 compliant) | ||
paperless recorder
DX1004-3-4-2/A1, DX1004-3-4-2/A2, DX1004-3-4-2/A3, DX1004-3-4-2/C2, DX1004-3-4-2/C3, DX1004-3-4-2/F1, DX1004-3-4-2/H2, DX1004-3-4-2/H5, DX1004-3-4-2/M1, DX1004-3-4-2/N1, DX1004-3-4-2/N2, DX1004-3-4-2/N3, DX1004-3-4-2/P1, DX1004-3-4-2/R1, DX1004-3-4-2/TPS2, DX1004-3-4-2/TPS4, DX1004-3-4-2/USB1, DX1004-3-4-2/PM1, DX1004-3-4-2/CC1, DX1004-3-4-2/BT2, DX1004-3-4-2/CP1, DX1004-3-4-2/AS1,
-------------------------------------------------------------------
DX1006-3-4-2/A1, DX1006-3-4-2/A2, DX1006-3-4-2/A3, DX1006-3-4-2/C2, DX1006-3-4-2/C3, DX1006-3-4-2/F1, DX1006-3-4-2/H2, DX1006-3-4-2/H5, DX1006-3-4-2/M1, DX1006-3-4-2/N1, DX1006-3-4-2/N2, DX1006-3-4-2/N3, DX1006-3-4-2/P1, DX1006-3-4-2/R1, DX1006-3-4-2/TPS2, DX1006-3-4-2/TPS4, DX1006-3-4-2/USB1, DX1006-3-4-2/PM1, DX1006-3-4-2/CC1, DX1006-3-4-2/BT2, DX1006-3-4-2/CP1, DX1006-3-4-2/AS1,
--------------------------------------------------------------------------------------------------
DX1012-3-4-2/A1, DX1012-3-4-2/A2, DX1012-3-4-2/A3, DX1012-3-4-2/C2, DX1012-3-4-2/C3, DX1012-3-4-2/F1, DX1012-3-4-2/H2 DX1012-3-4-2/H5, DX1012-3-4-2/M1, DX1012-3-4-2/N1, DX1012-3-4-2/N2, DX1012-3-4-2/N3, DX1012-3-4-2/P1, DX1012-3-4-2/R1, DX1012-3-4-2/TPS2, DX1012-3-4-2/TPS4, DX1012-3-4-2/USB1, DX1012-3-4-2/PM1, DX1012-3-4-2/CC1, DX1012-3-4-2/BT2, DX1012-3-4-2/CP1, DX1012-3-4-2/AS1,
